应用领域与概述/Brief Introduction：

这个机器分为了特定三通接头装灌阀，不适主要用于水剂和膏霜类物品的装灌，有点对高黏度原辅料（如浓酱、香辛料酱、番茄酱、种衣剂、微乳剂、透明桌面剂等）的特效比效强烈，且误差高。这个机器分为了PLC可源程序管控，配上69英寸触碰屏组队操控界面设计，全面推行自己进瓶，自己装灌，自己出瓶，电器元件，气动弹簧元控制部件均分为了国际联盟的品牌，切实保障了优异的质量管理和持续平衡的特点。本主机械设备成分比较简单，操控便捷，是内地佳的重要性高黏度原辅料的装灌主机械设备。这个机器装备了控制渗漏与拔丝的装灌闷头，切实保障装灌立即后无渗漏，无拔丝。Filling valve, the machine USES special tee is suitable for the filling agent and cream products, especially for high viscosity material (such as thick sauce, chili sauce, tomato sauce, indicated, micro emulsion, suspending agent, etc.) of the effect is obvious, and high precision. The machine USES PLC programmable control, with 6 inch touch screen man-machine interface system, implements the automatic into the bottle, automatic filling, automatic bottle, electric, pneumatic components adopt international brand, to ensure that the performance of the outstanding quality and lasting stability. This equipment has simple structure, convenient operation, is the ideal filling equipment for high viscosity material. The machine is equipped with prevent drip with wire filling cocks, ensure filling after the completion of a drip-tight, no drawing.

优点和缺点/Characteristic：

◆把控好程序——使用三菱数控平台PLC把控好程序，灌装设备标准容量随机性稍微调整。Control system adopt mitsubishi PLC control system, filling dose random tweaks◆实操菜单栏——65英寸彩屏手触式实操菜单栏，抽象概念十分简单、安全性可靠性Interface - 6 inches color hand touch interface operation, intuitive and simple, safe and reliable◆模块改良——上下料有防漏滴安装，可选择原材料的特点有下潜装罐模块。（此模块能用）Improvements - blanking drip tight device, according to the material properties have diving filling function. (this function can be chosen)◆设施部件——均进行国际英文知名店牌的品牌，保持设施的的安全靠得住、准确度性好；Electrical components adopt international famous brand, to ensure the equipment safe and reliable, high accuracy;◆物理安全装置——广州POS机安全装置均选择优良304铝合金质作,见谅想要接受物料清单需要选择316L另结算用。Mechanical parts, machine parts are made of high quality 304 stainless steel material can be used if necessary contact 316 l in extra costs.◆运算检查测量——雷达回波图运算，对操作产能正确性造成。Counting test, real-time, intuitive reflect the yield of work.◆装灌检验——无瓶不灌、瓶数不是很不灌Bottle filling test - no bottle no filling, not enough◆运营时候——机器复合GMP规范要求，可不累拆御、洗涤运营。Maintenance - the machine is in line with the GMP requirements, easy disassembly, cleaning maintenance.◆调节样式参数——拆卸装灌样式参数时，只需要比较简单调节，方便办成。Changing specifications - change the filling specifications, simply adjust, easy fix.◆优质运行场景——运行场景了优质骨架，使机的操控场景进一步保养健康。（此优质运行场景能够 选择）Environmental protection configuration, configuration framework of environmental protection, make the operation of the machine environment more clean sanitation. (the environmental protection configuration can be selected)

技艺运作/technical parameters：

灌装生产线头数The number of filling head	8头（可以选择4ಌ、6、8、10、15个包装头）8 he♋ad (optional 4, 6, 8, 10, 12 filling head)
支持瓶径 Applicable bottles Drive	Ф33-Ф100 mm
计量校准准确度measure precision	±1%
罐装体积Canned capacity	150-1000ml
制造作用Production Capacity	2400-4000瓶/半小时2400-4000   bottles per hour
气源压力bleed pressure	0.7-0.9mpa
电    源Power Supply	380 伏/50 HZ
总 功 率The total power	0.5 kw
外形尺寸 boundary dimension	6000×850×1800 mm
重    量Weight	500kg
